Elevate your warehouse storage efficiency with our Tradition Pallet Racking system, meticulously crafted to meet the demands of modern industrial logistics. Engineered with precision and adhering to rigorous quality standards, our pallet racking solution ensures seamless organization and optimal space utilization.
| Model Number | PALLET RACK | Frame Structure Type |
90*70mm (3.54" * 2.76"), 110*70mm (4.33" * 2.76"), 120*70 mm (4.72" * 2.76") Bolted Upright frame with Baseplate |
| Depth |
1.5 - 2.6mm - Customized 0.059" - 0.102" - Customized |
Beam Type |
100-110-120-130 ... 180mm Box beam (3.94" - 4.33" - 4.72" - 5.12" ... 7.09" Box beam) |
| Weight Capacity | 5.000 - 25.000kg (11023 - 11339lb) | Beam Connector Type | Safety PIN |
| Width | 800 mm-1m2 (31" - 47") | Surface finish | Powder coating & Galvanized |
| Height | 2 - 12m (78" - 472") | Frame Punch Whole Type | Pitch 2" (50.8mm) |
The weight capacity ranges from 5,000kg to 25,000kg (11,023 - 113,391 lb) depending on the configuration, beam selection, and structural layout chosen for your storage requirements.
Yes. We provide customization for depth (ranging from 1.5mm to 2.6mm), height (from 2m up to 12m), and column widths to fit your specific warehouse architecture and pallet specifications.
Our racking components are available with durable powder coating and galvanized finishes. These protective layers provide long life and resist corrosion, even under highly demanding industrial environments.
No, the system is designed for simple and quick installation. The beams connect securely to the upright columns using a user-friendly locking mechanism that requires no special tools or advanced technical training.
The connection utilizes an integrated safety PIN connector system. This design provides maximum safety against accidental forklift impact, dislodgement, or manual tampering.
Yes, our Tradition Pallet Racking system is available in both bolted and welded upright configurations to match varying local building codes and structural engineer specifications.
